SPECIFICATION PARAMETER
MODEL AMX4 Features Specifications 100 mA constant. Height:1930mm kVp 50-125. Width:640mm mAs 0.4-320. Depth:1153mm 24 kVp stations. Weight:477kg 30 mAs stations. Movements: X-Ray tube MX-75 275k HU. Range:1334mm Focal spot .75mm. Lowest Position:663mm Dual motor drive Highest Position:1996mm (forward & reverse). Collimator: Variable speed drive. Full:43cmx43cm High frequency generator. radiographic coverage:40inch LED display. Electric solenoid locks.
SPECIFICATION PARAMETER
MODEL Genius 100 Mobile Features: Microprocesser based digital control panal. Feather touch membrane keyboard. Convenient auto programmefor better image quality. Manual mode selection Separate KVP,MAS&Sec, display X-Ray on audible tone. On / Off with overload circuit breaker. 3 Wheel Design- for maximum mobility. Automatic tube overload protection. Specifications: Tube Current:25mA,50mA,100mA Tube Voltage:40kVp - 100kVp Timer:0.02 sec to 6 sec solid state Power:8KW Rectification:Full wave rectififed Length:1200mm Width:650mm Height:1880mm
SPECIFICATION PARAMETER
MODEL Genius 100 Mobile Features: Microprocesser based digital control panal. Feather touch membrane keyboard. Convenient auto programmefor better image quality. Manual mode selection Separate KVP,MAS&Sec, display X-Ray on audible tone. On / Off with overload circuit breaker. 3 Wheel Design- for maximum mobility. Automatic tube overload protection. Specifications: Tube Current:25mA,50mA,100mA Tube Voltage:40kVp - 100kVp Timer:0.02 sec to 6 sec solid state Power:8KW Rectification:Full wave rectififed Length:1200mm Width:650mm Height:1880mm
SPECIFICATION PARAMETER
MODEL Brivo XR 115 Features: A 100mA machine for better images across anatomies. 200kHz frequency for uniform radiation. A less than 3kg push force – 50% easier to move than most other models in the market. A 10% smaller footprint. Imaging: A 100mA X-ray that promises great imaging across anatomies. It is also 40% faster!. A 200kHz X-ray for great imaging and efficient dosage. The Brivo XR115 200kHz generator is so fast that the X-ray emission is extremely uniform with an efficient X-ray spectrum!.
SPECIFICATION PARAMETER
MODEL AMX4 Features Specifications 100 mA constant. Height:1930mm kVp 50-125. Width:640mm mAs 0.4-320. Depth:1153mm 24 kVp stations. Weight:477kg 30 mAs stations. Movements: X-Ray tube MX-75 275k HU. Range:1334mm Focal spot .75mm. Lowest Position:663mm Dual motor drive Highest Position:1996mm (forward & reverse). Collimator: Variable speed drive. Full:43cmx43cm High frequency generator. radiographic coverage:40inch LED display. Electric solenoid locks.
SPECIFICATION PARAMETER
MODEL AMX4 Features Specifications 100 mA constant. Height:1930mm kVp 50-125. Width:640mm mAs 0.4-320. Depth:1153mm 24 kVp stations. Weight:477kg 30 mAs stations. Movements: X-Ray tube MX-75 275k HU. Range:1334mm Focal spot .75mm. Lowest Position:663mm Dual motor drive Highest Position:1996mm (forward & reverse). Collimator: Variable speed drive. Full:43cmx43cm High frequency generator. radiographic coverage:40inch LED display. Electric solenoid locks.
SPECIFICATION PARAMETER
MODEL AMX4 Features Specifications 100 mA constant. Height:1930mm kVp 50-125. Width:640mm mAs 0.4-320. Depth:1153mm 24 kVp stations. Weight:477kg 30 mAs stations. Movements: X-Ray tube MX-75 275k HU. Range:1334mm Focal spot .75mm. Lowest Position:663mm Dual motor drive Highest Position:1996mm (forward & reverse). Collimator: Variable speed drive. Full:43cmx43cm High frequency generator. radiographic coverage:40inch LED display. Electric solenoid locks.
SPECIFICATION PARAMETER
MODEL AMX4 Features Specifications 100 mA constant. Height:1930mm kVp 50-125. Width:640mm mAs 0.4-320. Depth:1153mm 24 kVp stations. Weight:477kg 30 mAs stations. Movements: X-Ray tube MX-75 275k HU. Range:1334mm Focal spot .75mm. Lowest Position:663mm Dual motor drive Highest Position:1996mm (forward & reverse). Collimator: Variable speed drive. Full:43cmx43cm High frequency generator. radiographic coverage:40inch LED display. Electric solenoid locks.
SPECIFICATION PARAMETER
MODEL AMX4 Features Specifications 100 mA constant. Height:1930mm kVp 50-125. Width:640mm mAs 0.4-320. Depth:1153mm 24 kVp stations. Weight:477kg 30 mAs stations. Movements: X-Ray tube MX-75 275k HU. Range:1334mm Focal spot .75mm. Lowest Position:663mm Dual motor drive Highest Position:1996mm (forward & reverse). Collimator: Variable speed drive. Full:43cmx43cm High frequency generator. radiographic coverage:40inch LED display. Electric solenoid locks.
SPECIFICATION PARAMETER
MODEL Siemens Multimobil Series Multimobil 2.5 Output 2.5KW Multimobil 2.5 Exposure time min - 20 ms, max - 5 s Exposure technique two point technique Multimobil 2.5 kVp-range 40 - 100 kV Unit dimensions 65x142x142cm(WxHxL) Power consumption 3kVA mA range 13mA to 63mA mAs range 0.32mAs to 200mAs Focal spot 1.5mm x 1.5mm Inherent Filteration 0.5mm AI
SPECIFICATION PARAMETER
Model MultiMobil 10 Output power 10 kW Output waveform high frequency kV range 40 – 125 kV mA range 30 – 160 mA Exposure time 4 ms to 2.14 secs Exposure technique two point technique Inherent fltration 0.7 mm AI / 75 kV Collimator manually adjustable Time for collimator lamp 30 sec Power consumption 1 kVA Tube head angulations along x-ray tube axis: +180º/ -30º at yoke connection to arm ± 90º Unit dimensions 65 x 142 x 140 cm (w x h x l)
SPECIFICATION PARAMETER
Model Mars 3.5 X-Ray generator High Frequency(40KHz) Output power 3.5 kW Rad.kV 40 - 110 KV mAs range 1 to 200mAs Control panel Totally feather touch micro controller based Digital displays KV & mAs Dual action hand switch with retractable cord Provided X-ray tube head Monoblock version Collimator Manually operated with light- beam diaphram Collimator light on/off switching fromcontrol panel yes Power supply 230V (±10%), AC, 50/60 Hz., Single phase,15 Amps
SPECIFICATION PARAMETER
Model Mars 6 X-Ray generator High Frequency(40KHz) Output power 6 kW Rad.kV 40 - 110 KV mAs range 1 to 200mAs Control panel Totally feather touch micro controller based Digital displays KV & mAs Dual action hand switch with retractable cord Provided X-ray tube head Monoblock version Collimator Manually operated with light- beam diaphram Collimator light on/off switching fromcontrol panel yes Power supply 230V (±10%), AC, 50/60 Hz., Single phase,15 Amps
SPECIFICATION PARAMETER
MODEL Siemens Multimobil Series Multimobil 2.5 Output 2.5KW Multimobil 2.5 Exposure time min - 20 ms, max - 5 s Exposure technique two point technique Multimobil 2.5 kVp-range 40 - 100 kV Unit dimensions 65x142x142cm(WxHxL) Power consumption 3kVA mA range 13mA to 63mA mAs range 0.32mAs to 200mAs Focal spot 1.5mm x 1.5mm Inherent Filteration 0.5mm AI
SPECIFICATION PARAMETER
Model Multi Mobile 10 Output power 10 kW Output waveform high frequency kV range 40 – 125 kV mA range 30 – 160 mA Exposure time 4 ms to 2.14 secs Exposure technique two point technique Inherent fltration 0.7 mm AI / 75 kV Collimator manually adjustable Time for collimator lamp 30 sec Power consumption 1 kVA Tube head angulations along x-ray tube axis: +180º/ -30º at yoke connection to arm ± 90º Unit dimensions 65 x 142 x 140 cm (w x h x l)
